The protective wall HELO 16/20 PK

The protective wall is intended for the protection of flammable walls. Its function is to minimise the safety distance for sauna heaters.

Installed into the heater using mounting brackets.

A height-adjustable protective base is available as an accessory. It can be used to protect a flammable floor. It is also suitable for a waterproof tile floor. Adjustable legs in corners. When using only a protective base, the lateral safety distances need to be taken into consideration.

When using an uninsulated connecting tube, the insulated part of the chimney must reach the top of the protective wall. The safety distance for an uninsulated connecting tube is 400mm, if it is visible above the protective wall.

When using a pipe model water heater, the safety distance of the uninsulated pipe to the flammable structure must be taken into consideration.
The package includes:

• 2 sides
• 1 back wall
• 4 lower mounting brackets
• 4 upper mounting brackets
• 24 screws
• 24 bolts

Specifications:

• The material is coated with a heat-resistant coating and the steel is aluminium protected.
• 3 walls of the same height.
• Dimensions (mm): 500/590/800
• The safety distance between the heater and any flammable material:
  • HELO 16 PK - 120 mm
  • HELO 20 PK - 120 mm
